MikroTik L11UG-5HaxD Wi-Fi 6 AX600 USB LTE Outdoor
The MikroTik L11UG-5HaxD is a compact outdoor Wi-Fi 6 access point with USB LTE modem support — single-band 5 GHz 802.11ax AX600 2-chain (600 Mbps max), IPQ-5010 dual-core ARM32 at 800 MHz, 256 MB RAM, 128 MB NAND, RouterOS v7 License 4, 1× Gigabit Ethernet with 802.3af/at PoE-in (18–57V), 1× USB 2.0 Type-A for LTE modem or storage, passive cooling, IP66, -40°C to +70°C, MTBF ~100,000 hours at 25°C. CE, EAC, RoHS certified. USD 69.00. The correct low-cost compact outdoor 5 GHz Wi-Fi 6 AP for point-to-point or point-to-multipoint deployments, cellular LTE WAN failover via USB modem, and primary LTE connectivity in locations without wired broadband, with full RouterOS v7 management and IP66 weatherproofing.
We only offer IC Certified products. For international products, contact us.
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge.
The MikroTik L11UG-5HaxD is a compact single-band 5 GHz Wi-Fi 6 outdoor access point with a USB 2.0 port — a combination that positions it as a deployable wireless node wherever wired broadband is unavailable or unreliable, using a USB LTE modem as either the primary WAN connection or as an automatic failover link when the primary Ethernet uplink fails.
The single-band 5 GHz-only architecture is a deliberate design choice at this price point. The L11UG-5HaxD does not serve 2.4 GHz clients — it is a 5 GHz-only device. For outdoor fixed deployments where the AP is serving a defined set of known 5 GHz-capable client devices — rooftop CPE units, outdoor cameras, fixed wireless terminal adapters, or 5 GHz-capable laptops and mobile devices in an outdoor coverage zone — single-band 5 GHz is sufficient and eliminates the cost, complexity, and RF interference management of a dual-band radio. For mixed 2.4 GHz / 5 GHz outdoor coverage deployments, a dual-band MikroTik AP such as the wAP ax or NetMetal ax is the correct alternative.
The AX600 Wi-Fi 6 designation reflects the single 5 GHz radio's maximum theoretical throughput — 2-chain 802.11ax at 80 MHz channel width delivers up to 600 Mbps on the 5 GHz radio. Wi-Fi 6 (802.11ax) brings OFDMA, BSS colouring, WPA3 security, and MU-MIMO to the 5 GHz outdoor platform — meaningful improvements over Wi-Fi 5 (802.11ac) in high-interference outdoor RF environments where multiple overlapping networks compete for channel capacity. BSS colouring in particular reduces co-channel interference in dense outdoor deployments by allowing the L11UG-5HaxD to distinguish its own traffic from nearby networks operating on the same channel.
The USB 2.0 Type-A port is the hardware capability that distinguishes the L11UG-5HaxD from standard outdoor APs at this price point. In RouterOS, the USB port enables:
- **USB LTE modem — primary WAN:** For a deployment location without wired broadband — a remote agricultural site, a construction site, a temporary event venue, a rural monitoring station — a USB LTE modem inserted into the L11UG-5HaxD provides the primary internet connection. RouterOS manages the cellular data connection via the USB modem interface, providing NAT, firewall, routing, and VPN capabilities over the cellular WAN exactly as it would over a wired Ethernet WAN. For Canadian deployments, compatible USB LTE modems for Rogers, Bell, and TELUS networks should be confirmed against the MikroTik USB modem compatibility list — not all USB modems are compatible with RouterOS modem management.
- **USB LTE modem — WAN failover:** For a deployment where the primary WAN is the Gigabit Ethernet uplink (wired ISP connection, PoE uplink from a building switch), a USB LTE modem provides automatic WAN failover when the primary link fails. RouterOS failover scripting or routing policy detects primary link failure and switches outbound traffic to the cellular modem without manual intervention — maintaining connectivity for downstream devices during primary link outages.
- **USB storage:** A USB flash drive inserted into the L11UG-5HaxD provides local storage for RouterOS configuration backups, syslog storage, or data files for RouterOS scripting. For a remote deployment where local configuration backup is required, USB storage provides the backup medium without a network-accessible NAS or cloud storage dependency.
The single Gigabit Ethernet port with 802.3af/at PoE-in (18–57V) is the only wired interface — there is no second Ethernet port for wired pass-through. The L11UG-5HaxD is a single-port PoE-in device: one cable carries both power (PoE) and the network uplink from the upstream switch or PoE injector. For deployments requiring a wired downstream connection at the AP location, the L11UG-5HaxD does not provide it — a separate switch or the upstream PoE switch's port must serve that function.
The IPQ-5010 dual-core ARM32 at 800 MHz with 256 MB RAM is the same CPU platform as the wAP ax and NetMetal ax — consistent with MikroTik's 2024–2025 compact outdoor Wi-Fi 6 product platform. 256 MB RAM provides sufficient headroom for RouterOS v7 routing, firewall, VPN, USB modem management, and CAPsMAN CAP operation concurrently with the 5 GHz Wi-Fi 6 radio management load.
RouterOS v7 License 4 provides the complete routing, firewall, and VPN feature set including WireGuard VPN — the most relevant VPN protocol for the L11UG-5HaxD's primary use case. A remote site deployment using the L11UG-5HaxD as a USB LTE primary WAN device can establish a WireGuard tunnel from the L11UG-5HaxD back to a central RouterOS WireGuard server over the cellular connection, providing secure encrypted connectivity between the remote site and the central network over the public cellular internet. CAPsMAN integration allows the L11UG-5HaxD to operate as a managed CAP in a multi-AP deployment receiving SSID, security, and channel configuration from a central RouterOS controller.
The IP66 rating and -40°C to +70°C operating temperature make the L11UG-5HaxD suitable for permanent outdoor deployment across all Canadian climate zones. IP66's dust-tight and powerful water jet protection covers direct rain, snow, ice melt, and washdown exposure. The -40°C lower limit matches MikroTik's most robust outdoor devices — the L11UG-5HaxD operates in unheated outdoor enclosures across the full Canadian winter temperature range without enclosure heating. Passive cooling and no moving parts support the long-term unattended outdoor deployment model.
The compact form factor and USD 69.00 price point make the L11UG-5HaxD one of the most cost-effective outdoor Wi-Fi 6 + USB LTE-capable RouterOS devices in the current MikroTik catalogue. For large-scale rural connectivity, agricultural monitoring, or temporary site deployment programmes where per-node hardware cost is a primary constraint, the L11UG-5HaxD delivers Wi-Fi 6, IP66, RouterOS v7, and USB LTE capability at a price point that makes 10–100 node deployments economically viable without dedicated hardware budgets per site.
**Canadian market note:** Certifications are CE, EAC, and RoHS — no FCC or IC published. The L11UG-5HaxD is an active 5 GHz Wi-Fi 6 device. IC (ISED) certification is required for legal sale and operation in Canada. Confirm IC certification status with your MikroTik distributor before listing. This is a higher-priority certification advisory given the outdoor active wireless deployment context.
Key specifications:
- **Architecture:** ARM 32-bit
- **CPU:** IPQ-5010, dual-core ARM32, 800 MHz
- **RAM:** 256 MB
- **Storage:** 128 MB NAND
- **OS:** RouterOS v7, License 4
- **Wi-Fi 5 GHz:** 802.11a/n/ac/ax, Wi-Fi 6, 2-chain, 600 Mbps max
- **Wi-Fi speed class:** AX600 (single-band 5 GHz)
- **Wi-Fi security:** WPA3-PSK, WPA3-EAP, OWE, MFP
- **Ethernet:** 1× 10/100/1000 Mbps (PoE-in 802.3af/at, 18–57V)
- **USB:** 1× USB 2.0 Type-A
- **Max power consumption:** 13W
- **Max power without attachments:** 8W
- **Cooling:** Passive
- **IP rating:** IP66
- **Operating temperature:** -40°C to +70°C
- **MTBF:** ~100,000 hours at 25°C
- **Certifications:** CE, EAC, RoHS — no FCC, no IC published
- **Suggested price:** USD 69.00
- Product code
- L11UG-5HaxD
- Architecture
- ARM
- CPU
- IPQ-5010
- CPU core count
- 2
- CPU nominal frequency
- 800 MHz
- Operating System
- RouterOS v7
- Size of RAM
- 256 MB
- Storage size
- 128 MB
- Storage type
- NAND
- MTBF
- Approximately 100'000 hours at 25C
- Tested ambient temperature
- -40°C to 70°C
- Number of DC inputs
- 2 (PoE-IN, DC jack)
- DC jack input Voltage
- 12-28 V
- Max Power consumption
- 15 W
- Max power consumption without attachments
- 6 W
- Cooling type
- Passive
- PoE in
- Passive PoE
- PoE in input Voltage
- 18-28 V
- 10/100/1000 Ethernet ports
- 1
- Number of USB ports
- 1
- USB Power Reset
- Yes
- USB slot type
- USB type A
- Max USB current (A)
- 1.5
- Voltage Monitor
- Yes
- PCB temperature monitor
- Yes
- Wireless 5 GHz number of chains
- 2
- Wireless 5 GHz standards
- 802.11a/n/ac/ax
- Wireless 5 GHz chip model
- QCN-6102
- Wi-Fi generation
- Wi-Fi 6
- Wireless 5 GHz Max data rate
- 2400 Mbit/s
- Certification
- CE, FCC, IC, EAC, ROHS
