MLAG-Ready Routers & Switches

The MikroTik CCR2216-1G-12XS-2XQ is MikroTik's flagship cloud core router — Amazon Annapurna Labs AL73400 16-core ARM64 at 2,000 MHz, Marvell Prestera Aldrin2 98DX8525 switch chip (L3 hardware offloading, 4× 25G CPU lines), 16 GB DDR4 RAM, 128 MB NAND, 2× M.2 SATA slots, RouterOS v7 License 6, 12× SFP28 (25G), 2× QSFP28 (100G), 1× GbE, RJ45 serial console, 2× hot-swap AC PSU (100–240V, 50–60 Hz), 4× hot-swap fans, 128W max / 80W without attachments, CPU + PCB + voltage monitors, IP20, -20°C to +60°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Includes 2× IEC cord, rack ears, cable management brackets, K-82 fastening set. USD 2,795.00.

The MikroTik CRS520-4XS-16XQ-RM is a high-density core and aggregation switch — 16× QSFP+ 40G ports, 4× SFP28 25G ports, 2× SFP28 25G combo ports (shared with Ether1–2), 2× Gigabit Ethernet management ports, Marvell Prestera 98CX8514 switch ASIC, quad-core ARM64 AL21400 at 1,400 MHz, 2 GB RAM, 1 GB NAND, dual-boot RouterOS v7 License 6 / SwitchOS, dual hot-swap PSU slots (each 500W, 1,000W combined), 2× hot-swap fan trays, RJ45 serial console, 1U rackmount, -10°C to +50°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS certified.

The MikroTik CRS518-16XS-2XQ-RM is a 1U rack enterprise switch — Marvell 98DX8525 Prestera Aldrin2 switch ASIC, QCA9531 management CPU (MIPSBE, 650 MHz), 64 MB RAM, 16 MB FLASH, RouterOS v7 License 6, 16× SFP28 (25G, backward compatible 10G/1G), 2× QSFP28 (100G), 1× 10/100 Ethernet (management), RJ45 serial console, USB-A 1A, 2× hot-swap AC PSUs (100–240V), 4× hot-swap fans, 95W max / 45W without attachments, 1.2 Tbps switching capacity, IP20, -40°C to +70°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Includes rack ears, 2× IEC cord, K-54 kit. USD 1,595.00.

The MikroTik CRS812 DDQ (CRS812-8DS-2DQ-2DDQ-RM) is MikroTik's most powerful switch to date — a 1U rackmount 400G aggregation platform that makes 50G, 200G, and 400G connectivity accessible at a price point that was previously unimaginable for these speeds. It combines 8× 50G SFP56, 2× 200G QSFP56, and 2× 400G QSFP56-DD ports with full breakout mode support down to 1G/2.5G/5G/10G/25G/50G, a quad-core 2 GHz ARM64 AL52400 CPU, Marvell 98DX7335 switch chip, 4 GB RAM, dual redundant hot-swap PSUs, 4× hot-swap cooling fans, and RouterOS v7 License Level 6 — all at USD 1,295. Top-of-rack leaf, campus core, service provider aggregation, AI cluster fabric, or media workflow backbone — the CRS812 DDQ is built for all of them.

The MikroTik CRS326-4C+20G+2Q+RM is a high-density 25G rackmount switch — 20× SFP28 25G ports, 4× combo ports (SFP28 25G or 10/100/1000/2500/5000/10G RJ45 each), 2× QSFP+ 40G uplink ports, Marvell Prestera 98CX8121 switch ASIC, quad-core ARM64 AL21400 at 1,400 MHz, 2 GB RAM, 1 GB NAND, dual-boot RouterOS v7 License 6 / SwitchOS, dual hot-swap PSU slots (2× 250W, 500W combined), 2× hot-swap fan trays, RJ45 serial console, 1U rackmount, -10°C to +50°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS certified.

The MikroTik CRS510-8XS-2XQ-IN is a compact 1U 100 Gigabit data centre switch — 8× 25G SFP28 ports + 2× 100G QSFP28 ports, Marvell 98DX4310 Prestera switch ASIC, single-core MIPSBE QCA9531 at 650 MHz, 128 MB RAM, 32 MB FLASH, RouterOS v7 License 5 / SwitchOS (dual-boot), 1× 10/100 Ethernet management port, RJ45 serial console, 5 power input options (2× hot-swap AC PSU slots 100–240V + DC jack 36–57V + 802.3bt PoE-in 42.5–57V + 2-pin terminal 36–57V), 2-fan active cooling, IP20, -40°C to +70°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS certified. Includes 2× IEC cord, rack ears for CRS510, K10 screw kit, connector plug.

The MikroTik CRS354-48P-4S+2Q+RM is a high-density 1U rackmount dual-boot PoE switch — QCA9531 single-core MIPSBE at 650 MHz, 128 MB RAM, 32 MB flash, RouterOS v7 License 5 or SwitchOS, 48× GbE 802.3af/at PoE-out (auto-sensing + passive PoE + low voltage PoE) + 4× SFP+ 10G + 2× QSFP+ 40G, 168 Gbps non-blocking throughput, 336 Gbps switching capacity, 235 Mpps forwarding rate, 1× AC input 100–240V, 700W total PoE output, 800W max / 85W without attachments, 4 fans, RJ45 serial console, IP20, 443 × 382 × 44 mm, -20°C to +60°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Includes IEC cord, cable management brackets, rackmount ears, rear support ears, K-48 fastening set. Free software updates for life of product or minimum 5 years from purchase.

The MikroTik CCR2116-12G-4S+ is a 1U rack-mount ISP edge router — Amazon Annapurna Labs AL73400 16-core ARM64 at 2,000 MHz, Marvell Aldrin 98DX3255 switch chip (L3 hardware offloading, 4× 10G CPU lines), 16 GB DDR4 RAM, 128 MB NAND, 1× M.2 PCIe slot, RouterOS v7 License 6, 12× GbE (switch chip) + 1× GbE (direct CPU management), 4× SFP+ (10G), RJ45 serial console, 2× AC PSU (100–240V, 47–63 Hz), 4 fans, 83W max / 60W without attachments, CPU + PCB + voltage monitors, mode button, 443 × 199 × 44 mm, -20°C to +60°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Includes 2× IEC cord, rack bracket, K-57 kit. USD 995.00.

The MikroTik CRS504-4XQ-OUT is a compact outdoor IP66 100 Gigabit switch — 4× 100G QSFP28 ports (backward compatible: 100G / 40G / 4×25G breakout / 4×10G breakout / 1G), Marvell 98DX4310 Prestera switch ASIC, single-core MIPSBE QCA9531 at 650 MHz, 128 MB RAM, 32 MB FLASH, RouterOS v7 License 5 / SwitchOS (dual-boot), 1× 10/100 Ethernet management port, RJ45 serial console, 3 power inputs (DC jack 36–57V + 802.3bt PoE-in 43–57V + 2-pin terminal 36–57V), passive cooling, IP66, -40°C to +70°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS certified. Includes 48V 0.95A power adapter, Gigabit PoE injector, hose clamp ×2, K-41 fastening set, K-72 fastening set.

The MikroTik CRS504-4XQ-IN is a compact 100G switch — Marvell 98DX4310 switch ASIC, QCA9531 management CPU (MIPSBE, 650 MHz), 64 MB RAM, 16 MB FLASH, RouterOS v7 License 5, 4× QSFP28 (100G, breakout-capable to 16× 25G), 1× 10/100 Ethernet (management), RJ45 serial console, 2× AC hot-swap PSU slots (100–240V), 3× DC inputs (DC jack 36–57V + 802.3bt PoE-in 43–57V + 2-pin terminal 36–57V), 2 fans, 41W max / 25W without attachments, PCB temperature monitor, IP20, -40°C to +70°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Includes rack ears, K10 screw kit, 2× IEC cord. USD 799.00.
