25G/100G Solutions

The MikroTik CCR2216-1G-12XS-2XQ is MikroTik's flagship cloud core router — Amazon Annapurna Labs AL73400 16-core ARM64 at 2,000 MHz, Marvell Prestera Aldrin2 98DX8525 switch chip (L3 hardware offloading, 4× 25G CPU lines), 16 GB DDR4 RAM, 128 MB NAND, 2× M.2 SATA slots, RouterOS v7 License 6, 12× SFP28 (25G), 2× QSFP28 (100G), 1× GbE, RJ45 serial console, 2× hot-swap AC PSU (100–240V, 50–60 Hz), 4× hot-swap fans, 128W max / 80W without attachments, CPU + PCB + voltage monitors, IP20, -20°C to +60°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Includes 2× IEC cord, rack ears, cable management brackets, K-82 fastening set. USD 2,795.00.

The MikroTik CRS520-4XS-16XQ-RM is a high-density, enterprise-grade 100G core switch combining the switching power of a Marvell 98CX8410 chip with the processing muscle of a quad-core 64-bit ARM CPU running at 2 GHz and 4 GB of RAM. It provides 16 × 100G QSFP28 ports, 4 × 25G SFP28 ports, and 2 × 10G Ethernet ports, running RouterOS v7 for advanced Layer 2 and Layer 3 network management. Two hot-swap power supplies and four hot-swap fans are included as standard, making it a resilient, future-proof solution for data centre and enterprise core network deployments.

The MikroTik ROSE Data Server (RDS2216) is a 1U rackmount enterprise platform that converges 100G networking, 20-bay U.2 NVMe storage, and OCI container compute into a single device — eliminating the cost, complexity, and power overhead of separate storage, networking, and compute infrastructure. Powered by a 16-core AL73400 ARM64 CPU at 2 GHz, 32 GB DDR4 RAM, dual hot-swap PSUs (max 286W), 2× 100G QSFP28, 4× 25G SFP28, 4× 10G SFP+, 2× 10G Ethernet, and the special ROSE edition of RouterOS v7 License Level 6 — it runs MinIO, Nextcloud, PostgreSQL, RAID, NVMe-TCP, iSCSI, BTRFS, and TCG-Opal self-encrypting drives with no subscriptions, no paywalls, and no vendor lock-in. You buy it. You own it. Forever.

The MikroTik CRS518-16XS-2XQ-RM is an enterprise-grade 1U rack-mount switch delivering 16× 25 Gigabit SFP28 ports and 2× 100 Gigabit QSFP28 ports, all driven by the Marvell Prestera Aldrin2 (98DX8525) switch chip with a non-blocking switching fabric of up to 1.2 Tbps. The 25G SFP28 ports are fully backward compatible with 10G and 1G SFP devices. Dual hot-swap power supplies with a 100–240 V AC input range and four active cooling fans ensure reliable operation in demanding data centre and enterprise deployments. Running RouterOS v7 with a Level 6 licence, it supports VLAN (802.1Q, 802.1ad), L3 hardware offloaded routing, ACL, LACP, MLAG, and Jumbo frames — making it a powerful and cost-effective core or aggregation switch for high-density 25G and 100G networks.

The MikroTik CRS510-8XS-2XQ-IN is a compact 1U 100 Gigabit data centre switch — 8× 25G SFP28 ports + 2× 100G QSFP28 ports, Marvell 98DX4310 Prestera switch ASIC, single-core MIPSBE QCA9531 at 650 MHz, 128 MB RAM, 32 MB FLASH, RouterOS v7 License 5 / SwitchOS (dual-boot), 1× 10/100 Ethernet management port, RJ45 serial console, 5 power input options (2× hot-swap AC PSU slots 100–240V + DC jack 36–57V + 802.3bt PoE-in 42.5–57V + 2-pin terminal 36–57V), 2-fan active cooling, IP20, -40°C to +70°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS certified. Includes 2× IEC cord, rack ears for CRS510, K10 screw kit, connector plug.

The MikroTik CRS504-4XQ-OUT is a compact outdoor IP66 100 Gigabit switch — 4× 100G QSFP28 ports (backward compatible: 100G / 40G / 4×25G breakout / 4×10G breakout / 1G), Marvell 98DX4310 Prestera switch ASIC, single-core MIPSBE QCA9531 at 650 MHz, 128 MB RAM, 32 MB FLASH, RouterOS v7 License 5 / SwitchOS (dual-boot), 1× 10/100 Ethernet management port, RJ45 serial console, 3 power inputs (DC jack 36–57V + 802.3bt PoE-in 43–57V + 2-pin terminal 36–57V), passive cooling, IP66, -40°C to +70°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS certified. Includes 48V 0.95A power adapter, Gigabit PoE injector, hose clamp ×2, K-41 fastening set, K-72 fastening set.

The MikroTik CRS504-4XQ-IN is a compact 100G switch — Marvell 98DX4310 switch ASIC, QCA9531 management CPU (MIPSBE, 650 MHz), 64 MB RAM, 16 MB FLASH, RouterOS v7 License 5, 4× QSFP28 (100G, breakout-capable to 16× 25G), 1× 10/100 Ethernet (management), RJ45 serial console, 2× AC hot-swap PSU slots (100–240V), 3× DC inputs (DC jack 36–57V + 802.3bt PoE-in 43–57V + 2-pin terminal 36–57V), 2 fans, 41W max / 25W without attachments, PCB temperature monitor, IP20, -40°C to +70°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Includes rack ears, K10 screw kit, 2× IEC cord. USD 799.00.

The MikroTik CCR2004-1G-12S+2XS is a 1U rackmount cloud core router — AL32400 quad-core ARM64 at 1,700 MHz, 4 GB ECC RAM, 128 MB NAND flash, RouterOS v7 License 6, 1× GbE + 12× SFP+ 10G + 2× SFP28 25G, RJ45 serial console, dual redundant AC input (100–240V, 2× IEC cords), 60W max / 31W without attachments, 2 fans, IP20, 443 × 224 × 44 mm, -20°C to +60°C, MTBF ~200,000 hours at 25°C. CE, EAC, RoHS — no FCC, no IC. Highest single-core performance in the CCR2004 family — up to 3.4 Gbps single IPsec tunnel, strong BGP feed processing. Includes 2× IEC cords, K10 screw and feet kit, rackmount bracket. Free software updates for life of product or minimum 5 years from purchase.

The MikroTik CRS418-8P-8G-2S+RM is the wireless-free 1U rackmount edition of the CRS418 platform — all the switching, routing, PoE, and 10G uplink capability of the CRS418 series without the Wi-Fi 6 radio. It combines 16× Gigabit Ethernet ports (8 with 802.3af/at PoE-out), a dedicated Gigabit management port, 2× 10G SFP+ uplinks, the quad-core IPQ-8072A 2.2 GHz ARM64 CPU with L3 hardware offloading, 1 GB RAM, dual redundant AC power supplies, USB 3.0, and RouterOS v7 License Level 5 — a clean, no-compromise rackmount switch-router for environments where Wi-Fi is handled separately or not needed at all.

The SYNOXX EQP29Y-10D is a 100G QSFP28 LR4 optical transceiver delivering 100Gbps
transmission over single-mode fiber up to 10km using four LAN Wavelength Division
Multiplexing (LWDM) channels around 1310nm — a standard LC duplex interface
enabling long-reach 100G data centre interconnects, inter-building campus links,
and metro-edge telecom connections without MPO ribbon fiber infrastructure.
Compliant with QSFP28 MSA and IEEE 802.3ba, featuring a CAUI-4 (4×25G) electrical
host interface, integrated Digital Diagnostic Monitoring (DDM) for real-time
temperature, voltage, TX/RX power, and bias current monitoring, and low power
consumption. Hot-pluggable, RoHS compliant, and IC Certified.
